TYSIMの抗打ち工事装置CO.、株式会社。
--小さい回転式掘削装置のリーダー!
|
商品の詳細:
お支払配送条件:
|
| 山の直径: | 300~1050のmm | 最大。シリンダーストローク: | 135mm |
|---|
| Technical specification | 13 modules combination KP315 |
18 modules combination KP380 |
| Pile diameter | 300~1050 mm | 600~1800 mm |
| Max. rod pressure | 280 kN | 600 kN |
| Max. cylinder stroke | 135 mm | 150 mm |
| Max. crowd pressure | 34.3 MPa | 34.3 MPa |
| Max. single cylinder flow | 20 L/min | 30 L/min |
| Quantity/8h | 60/8 h | 48/8 h |
| Max. single cutting height | ≤300 mm | ≤300 mm |
| Excavator capacity | ≥20 | ≥35 |
| Single module weight | 100 kg | 230 kg |
| Single module size | 520*444*316 mm | 696*566*350 mm |
| Operating size | Φ2098*4000 mm | Φ3316*4840 mm |
| Overall weight | 1.7 t | 4.5 t |
Why Choose Us?
1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.
2. Supply professional customized service to meet all your requirements.
3. Our rotary drilling rigs have been sold to more than 20 counstries, such as Russia, Australia, Thailand, Zambia and others.
4. Competitive price.
FAQ
Q1: What is the Warranty of the Rotary Drilling Rig?
The warranty period for new machine is half a year or 1000 working hours, whichever comes first will be applied.
Please contact with us for detailed Warranty Regulation.
Q2: What's your service ?
We can offer professional technical support and good after-sale service to you.
Modification methods will be different according to different models and configurations of your owned excavators.
Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.
Before modifying, you need to confirm technical specification.
